100NC/X High Speed Vertical Circular Saw Angled Push Metal Cutting Heavy Duty

Supply Ability : 500 Sets Per Year

Cutting precision : ±0.05mm

Payment Terms : FOB

Mechanical control : Intelligent control，Automation

Color : White，Black

FAT : Sample trial cutting verification

Dimension : 2044 x 2273 x 1809

Hydraulic oil : Reusable

Saw type : Diagonal cut

Name : JSSCD- 100NC/X CNC High Speed Circular Saw Machine

Use : Material cutting

Cutting debris removal device : Chain plate chip conveyer

Cuttable material : Carbon steel，Stainless steel，Alloy steel，Aluminum，Aluminum alloy，Copper，Copper alloy，Titanium alloy，PA

Feeding precision : ±0.1mm

Safety protection devices : Emergency braking，Anti-splash shield

Brand Name : JSSCD

Model Number : JSSCD-100NC/X

Certification : HB24Q00435R0S HB24E0025 HB24S00242R0S8R0S

Place of Origin : China

MOQ : 1

Delivery Time : 7-60 work days

Packaging Details : depending on the machine model

Application : Automobile manufacturing，Aerospace，Rail transit，Mechanical equipment，Hardware tools，Ship building，Building material，Pipeline engineering，Mold manufacturing，Electronics manufacturing

Condition : New

Contact Now

JSSCD-100NC/X CNC High Speed Circular Saw for Metal Cutting(Angled-Push)
Product Overview
This advanced CNC high-speed circular saw delivers precision angular cuts with a signature 15-degree downward cutting trajectory. Designed for modern industrial environments, it combines rapid processing, intelligent automation, and exceptional accuracy to enhance productivity in metal fabrication.
Key Features
  • 15-degree downward cutting mechanism reduces impact forces for consistently smooth, flat cut surfaces
  • Processes diverse metal profiles including tubing and structural shapes
  • High-performance drive system with rigid clamping apparatus for dependable workpiece fixation
  • Sophisticated intelligent controller precisely regulates feed rates and cutting angles
  • Intuitive HMI interface for effortless preconfiguration of cutting sequences
  • Optional automated material handling system for continuous batch processing
Technical Specifications
Model Unit JSSCD-100NC/X
Mainframe dimensions mm 2044*2273*1809
Bar & round pipe mm 20-100
Angle bar & square bar mm 20-85
Saw blade size mm φ360*2.25*2.6*φ40
Spindle motor power KW 11(6p)
Spindle speed rpm 20-150
Feed servo motor KW 1.5
Hydraulic drive motor power KW 2.25(4p)
Rated pressure of the hydraulic system mpa 4-5
Cut off feed mode AC servo motor & ball screw / 15° cutting-in
Main clamping method Hydraulic type / one set each for horizontal and 15°
Operational Benefits
  • Improves material utilization
  • Reduces waste generation
  • Accelerates cycle times
  • Shortens delivery schedules
  • Optimizes labor deployment
100NC/X High Speed Vertical Circular Saw Angled Push Metal Cutting Heavy Duty 100NC/X High Speed Vertical Circular Saw Angled Push Metal Cutting Heavy Duty 100NC/X High Speed Vertical Circular Saw Angled Push Metal Cutting Heavy Duty 100NC/X High Speed Vertical Circular Saw Angled Push Metal Cutting Heavy Duty
Frequently Asked Questions
Q1: Are you a manufacturer or a trading company?
We are a professional manufacturer of saw blade grinders with a 30,000 square meter factory and dedicated technical team.
Q2: Where is your factory located?
Our factory is located in Nantong City, Jiangsu Province, China, approximately 1.5 hours from Shanghai Hongqiao station.
Q3: What is your factory acceptance test method?
You can send sample material for test cutting. We'll provide detailed cutting data and a video of the operation.
Q4: What is your method of transaction?
We use FOB (Free On Board) transactions.
Q5: How about your delivery time?
Typically 7-60 work days after order confirmation, depending on items and quantity.
Q6: What are your payment terms?
T/T 30% deposit, 70% balance before shipment. Other methods available upon request.
Q7: Does the band saw blade have any international certifications?
Yes, we have obtained CE and ISO international certifications.
